APIE KR220C Rotary Drilling Rig: 220 KNm, 60m/Min, Used for
Borehole Drilling, 51m Depth
Introducing the APIE KR220C Rotary drilling rig:
1. This rotary drilling machine is fully electronically controlled,
ensuring precise and efficient operation.
2. With its user-friendly interface, the operation process is
simplified, allowing for easy handling.
3. It holds GB certification and EU EN16228 standard certification,
meeting industry-approved safety and quality standards.
4. Boasting a wide application range, this rig offers high
construction efficiency and maintains stable performance throughout
various projects.
5. Rest assured of its exceptional quality while enjoying cost
savings compared to alternatives in the market.
The APIE KR220C Rotary Drilling Rig combines power, speed, and
reliability, making it an excellent choice for borehole drilling
tasks. With a depth capacity of 51m, this rig offers the
versatility and efficiency necessary for successful construction
projects.
| Performance Parameter | Unit | Value |
| Max. torque | kN.m | 220 |
| Max. drilling diameter | mm | 1800/2000 |
| Max. drilling depth | m | 64/51 |
| Working speed | rpm | 6~28 |
| Max. cylinder pressure | kN | 210 |
| Max. hoist capacity | kN | 220 |
| Main winch pull force | kN | 230 |
| Main winch speed | m/min | 60 |
| Auxiliary winch pull force | kN | 90 |
| Auxiliary winch speed | m/min | 60 |
| Max. cylinder stroke | mm | 5000 |
| Mast side raking | ° | ±5 |
| Mast raking forward | ° | 5 |
| System pressure | mpa | 35 |
| Pilot pressure | mpa | 4 |
| Max. walking speed | km/h | 2.2 |
| Max. pull force | kN | 430 |
| Operating height | mm | 21082 |
| Operating width | mm | 4300 |
| Transport height | mm | 3360 |
| Transport width | mm | 3000 |
| Transport length | mm | 15300 |
| Total weight | t | 66 |
| Type | Model | Manufacturer Year | Working Hours | Classis | Kelly bar/Max.depth |
| KR150-5 | 16KR150G-005 | 20171102 | 5000 | ZG3255 | 325-4*10
37m |
| KR220C-12 | 19KR220C012 | 20191207 | 1788 | CAT330D | 440-4*13.5
51m |
| KR220C-16 | 20KR220C016 | 20201024 | 1873 | CAT330D | 440-4*13.5
51m |
| KR220C-15 | 20KR250C015 | 202005 | 1994 | CAT330D | 440-4*13.5
51m |
| KR90C-19 | 18KR90C019 | 20180507 | 3738 | CAT318D | 273-3*9.5
24m |
| KR90L-23 | 20KR90L023 | 20200714 | 1500 | CLG915E | 299-4*8.5
28m |
| KR90L-26 | 19KR90A026 | 20200102 | 2258 | CLG915E | 299-4*8.5
28m |
FAQ
1: How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment
2: What can you buy from us?
Rotary Drilling Rig,Hydraulic Pile Breaker,Clamshell Telescopic Arm
3: Why should you buy from us not from other suppliers?
APIE is the only one focused on the development civil for small and
medium-sized enterprise, which is specialized in the rotary
drilling rig and obtains more than 40 pile driving products patent.
APIE core team is instituted by the senior researchers.
