    34.3MPa Multifunctional Drilling Rig 150kNm Rotary Hole Auger CFA Foundation Pile Drill Rig

    Ask Lasest Price
    Brand Name : TYSIM
    Model Number : KR150M
    Certification : CE and ISO9001
    Price : $280000+
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 2 sets/month
    Delivery Time : 20-25 days
    • Product Details
    • Company Profile

    34.3MPa Multifunctional Drilling Rig 150kNm Rotary Hole Auger CFA Foundation Pile Drill Rig

    Reliable Performance Hydraulic CFA Continuous Multifunctional Rotary Hole Auger Drilling Piling Rig


    Product description

    1. erialized products have different models, different capabilities, and multiple choices to meet the needs of different customers.
    2.Power head can be mechanically / hydraulically shifted. Suitable for various drilling methods such as down-the-hole hammer, heel pipe, full casing and alloy rotation
    3.The drilling rig is equipped with a hydraulic clamping shackle device and an automatic shackle, which reduces auxiliary time and labor intensity.
    4.The crawler chassis equipped with a turning device on the car makes the whole machine move and find holes more conveniently and quickly.

    Technical Specification

    Technical specification of KR150M rotary drilling rig
    Torque150 kN.m
    Max. diameter750 mm
    Max. drilling depth17 m
    Max. crowd pull400 kN
    Auxiliary winch line pull60 kN
    Auxiliary winch line speed79 m/min
    Mast inclination(lateral)±5°
    Mast inclination(forward)
    Mast inclination(backward)15°
    Max. operating pressure34.3 MPa
    Pilot pressure4 Mpa
    Operating height21160 mm
    Operating width4100 mm
    Transport height3305 mm
    Transport width3100 mm
    Transport length13000 mm
    Overall weight42 t


    FAQ

    1: What is the Warranty of the Rotary Drilling Rig?

    The warranty period for new machine is a year or 2000 working hours, whichever comes first will be applied.
    Please contact with us for detailed Warranty Regulation.


    2: What's your service ?

    We can offer professional technical support and good after-sale service to you.
    Modification methods will be different according to different models and configurations of your owned excavators.
    Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.
    Before modifying, you need to confirm technical specification.


    3: What can you buy from us?
    Rotary Drilling Rig,Hydraulic Pile Breaker,Clamshell Telescopic Arm


    4: Why should you buy from us not from other suppliers?
    APIE is the only one focused on the development civil for small and medium-sized enterprise, which is specialized in the rotary drilling rig and obtains more than 40 pile driving products patent. APIE core team is instituted by the senior researchers.
