230kg 4.5t Concrete Pile Cutting Machine 1800mm Round Hydraulic Pile Cutter

Ask Lasest Price
Brand Name :	APIE
Model Number :	KP380
Certification :	CE and ISO9001
Price :	$41000+
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	10 sets/month
Delivery Time :	5-7 days

Add to Cart

Product Details
Company Profile

230kg 4.5t Concrete Pile Cutting Machine 1800mm Round Hydraulic Pile Cutter

APIE KP 380 Construction Works Concrete Pile Cutter Hydraulic Round Pile Breaker Machine

Products Feature

1. The leading hydraulic pile breaker/cutter, with five patented technologies, is the most efficient equipment to crushing the foundation piles and fills the domestic gap;

2. Using advacced modular design, it can be used for crushing piles of different diameters by changing the module combination quantity;

3. It can be installed on a large variety of construction machinery, realizing the versatility and economy.

Technical Specification

Technical specification	13 modules combination KP315	18 modules combination KP380
Pile diameter	300~1050 mm	600~1800 mm
Max. rod pressure	280 kN	600 kN
Max. cylinder stroke	135 mm	150 mm
Max. crowd pressure	34.3 MPa	34.3 MPa
Max. single cylinder flow	20 L/min	30 L/min
Quantity/8h	60/8 h	48/8 h
Max. single cutting height	≤300 mm	≤300 mm
Excavator capacity	≥20	≥35
Single module weight	100 kg	230 kg
Single module size	520×444×316 mm	696×566×350 mm
Operating size	Φ2098×4000 mm	Φ3316×4840 mm
Overall weight	1.7 t	4.5 t

FAQ

1: What is the Warranty of the Rotary Drilling Rig?

The warranty period for new machine is a year or 2000 working hours, whichever comes first will be applied.
Please contact with us for detailed Warranty Regulation

2: Why should you buy from us not from other suppliers?
APIE is the only one focused on the development civil for small and medium-sized enterprise, which is specialized in the rotary drilling rig and obtains more than 40 pile driving products patent. APIE core team is instituted by the senior researchers.

3: What's your service ?

We can offer professional technical support and good after-sale service to you.
Modification methods will be different according to different models and configurations of your owned excavators.
Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.
Before modifying, you need to confirm technical specification.

4: How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment
