Efficient Hydraulic Pile Breaker/Cutter: Versatile and Easy to
Operate
Products Description
1. Our leading hydraulic pile breaker/cutter, equipped with five
patented technologies, is the most efficient equipment for crushing
foundation piles and addressing the market gap.
2. Featuring an advanced modular design, it can crush piles of
different diameters by adjusting the quantity and combination of
modules, offering versatility and adaptability.
3. This hydraulic pile breaker/cutter can be installed on a wide
range of construction machinery, providing cost-effectiveness and
versatility for various project requirements.
4. With its user-friendly design, our equipment can be simply
operated with minimal staff, streamlining operations and reducing
labor requirements.
5. Experience efficient pile crushing as our equipment is designed
to crush the piles wholly, ensuring optimal performance and
results.
The use of an adjustable chain enhances the adaptability of our
hydraulic pile breaker/cutter, allowing for precise and effective
pile crushing.
6. Enjoy the benefits of a full hydraulic drive system, ensuring
low-noise operation and minimizing disruptions in the work
environment.
Our equipment is designed for quick assembly, enabling convenient
transportation and enhancing overall operational efficiency.
Technical Specification
| KP400S/KP450S/KP500S Technical specification |
| Type | KP400S | KP450S | KP500S |
| Pile length (mm) | 250~400 | 350~450 | 400~500 |
| Max. rod pressure (kN) | 280 | 280 | 280 |
| Max. cylinder stroke (mm) | 135 | 135 | 135 |
| Max. crowd pressure (MPa) | 34.3 | 34.3 | 34.3 |
| Max. single cylinder flow(L/min) | 20 | 20 | 20 |
| Quantity/8h | 160 | 180 | 200 |
| Max. single cutting height(mm) | ≤300 | ≤300 | ≤300 |
| Excavating capacity (t) | ≥7 | ≥8 | ≥10 |
| Operating size (mm) | 1440×1440×1500 | 1490×1490×1500 | 1588×1588×1500 |
| Overall weight (t) | 0.55 | 0.57 | 0.8 |
FAQ
1: What is the Warranty of the Rotary Drilling Rig?
The warranty period for new machine is a year or 2000 working
hours, whichever comes first will be applied.
Please contact with us for detailed Warranty Regulation.
2: What's your service ?
We can offer professional technical support and good after-sale
service to you.
Modification methods will be different according to different
models and configurations of your owned excavators.
Before modifying, you need to provide configuration, mechanical and
hydraulic joints and others.
Before modifying, you need to confirm technical specification.
3: What can you buy from us?
Rotary Drilling Rig,Hydraulic Pile Breaker,Clamshell Telescopic Arm
4: Why should you buy from us not from other suppliers?
APIE is the only one focused on the development civil for small and
medium-sized enterprise, which is specialized in the rotary
drilling rig and obtains more than 40 pile driving products patent.
APIE core team is instituted by the senior researchers.
