150kNm 1300mm Used Piling Rig Hydraulic Drilling rig Borehole
Machine
Our Advantages
Engine
USA powerful Cummins engine, to maximize its working performance.
Certification
Our products have passed GB certification and EU EN16228 standard
certification, better dynamic and static stability design to ensure
construction safety.
Chassis
New and upgraded caterpillar chassis with high quality to ensure
the best performance of the whole machine.
Power head
The power head is designed with an extra option for drilling rock
to recuce the operation intensity of the operator.
| Performance Parameter | Unit | Value |
| Max. torque | kN.m | 150 |
| Max. drilling diameter | mm | 1300/1500 |
| Max. drilling depth | m | 42/52 |
| Working speed | rpm | 6~30 |
| Max. cylinder pressure | kN | 100 |
| Max. hoist capacity | kN | 150 |
| Main winch pull force | kN | 110 |
| Main winch speed | m/min | 78 |
| Auxiliary winch pull force | kN | 60 |
| Auxiliary winch speed | m/min | 60 |
| Max. cylinder stroke | mm | 3800 |
| Mast side raking | ° | ±3 |
| Mast raking forward | ° | 5 |
| System pressure | mpa | 34.3 |
| Pilot pressure | mpa | 3.9 |
| Max. walking speed | km/h | 2.8 |
| Max. pull force | kN | 229 |
| Tail radius of rotation | m | 4 |
| Operating height | mm | 16175 |
| Operating width | mm | 3390 |
| Transport height | mm | 3655 |
| Transport width | mm | 3390 |
| Transport length | mm | 14765 |
| Total weight | t | 40 |
| Type | Model | Manufacturer Year | Working Hours | Classis | Kelly bar/Max.depth |
| KR150-5 | 16KR150G-005 | 20171102 | 5000 | ZG3255 | 325-4*10
37m |
| KR220C-12 | 19KR220C012 | 20191207 | 1788 | CAT330D | 440-4*13.5
51m |
| KR220C-16 | 20KR220C016 | 20201024 | 1873 | CAT330D | 440-4*13.5
51m |
| KR220C-15 | 20KR250C015 | 202005 | 1994 | CAT330D | 440-4*13.5
51m |
| KR90C-19 | 18KR90C019 | 20180507 | 3738 | CAT318D | 273-3*9.5
24m |
| KR90L-23 | 20KR90L023 | 20200714 | 1500 | CLG915E | 299-4*8.5
28m |
| KR90L-26 | 19KR90A026 | 20200102 | 2258 | CLG915E | 299-4*8.5
28m |
FAQ
1: How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment
2: What can you buy from us?
Rotary Drilling Rig,Hydraulic Pile Breaker,Clamshell Telescopic Arm
3: What's your service ?
We can offer professional technical support and good after-sale
service to you.
Modification methods will be different according to different
models and configurations of your owned excavators.
Before modifying, you need to provide configuration, mechanical and
hydraulic joints and others.
Before modifying, you need to confirm technical specification.
4: What can you buy from us?
Rotary Drilling Rig,Hydraulic Pile Breaker,Clamshell Telescopic Arm
